Speck IG233-1200F-000 — 2 horsepower, 72-volt, three-phase, single-speed circulation pump for industrial and commercial applications

Description

Speck Pumps 72-V 2 HP Three Phase Single Speed Pump IG233-1200F-000

The Speck Pumps Model 72 offers the quality and design of a commercial pool pump for your residential or small commercial pool. This self-priming, all plastic pump is designed to provide durable, quiet operation, while maintaining premium high flow performance. The Speck Model 72 high performance pump is environmentally friendly, and uses only 100% recyclable plastic.

Speck Pumps 72-V Features:

• Three Phase Single Speed
• 2.0 HP
• 1.20 S.F.
• 2.40 THP
• 208-230/460 volts
• Premium energy efficient 3 phase 56 frame motor
• This 3 phase unit requires a motor starter
• Features a mechanical shaft seal that allows the pump to run dry for up to one hour without harming the pump
• Maintains high flow
• May be used in pools with salt concentrations up to 5000 ppm and temperatures up to 175° F
• Non-corrosive parts are made from 100% recyclable plastic
• Chemical and UV resistant
• Suction and discharge feature quick disconnect 2″ or 3″ unions for simple installation or maintenance
• Lock ring includes newly designed handles to conveniently remove the lid
• Engineered for safety, with a dielectric shaft sleeve to completely separate the pool water from the electric parts
• Heavy duty “1081” E-plus/extreme-E energy efficient motors provides for extra low energy consumption
• Large 56 frame, thermally protected motor with reuseable o-rings throughout
• PSC switchless design and extra large sealed ball bearings
• Motor is easily removed without disturbing the plumbing
• Includes a two year warranty on the motor and all pump parts, including normal wear of the mechanical seal.
• Every pump is thoroughly performance tested before leaving the Speck factory
